fischer Coated Panel System FCPS/5kg

Top Features

Approved for light partition walls.
Can be installed dry.
Up to 4 hours integrity and 2 hours insulation.
Excellent acoustic properties.

FireStop coated panel system for multiple service penetrations.

Advantages

Approved for light partition walls
Can be installed dry
No coatback required for services
Excellent acoustic properties
Asbestos and halogen free

fischer Coated Panel System FCPS is a rock fiber core which is coated on both sides with the ablative sealant FPC - fischer Panel Coating. FCPS is designed to provide effective and efficient firestopping seals in both vertical and horizontal applications. FCPS also helps to maintain the sound reduction index of a structure. The FCPS has been tested to BS 476 part 20 and 22, EN 1366-3 and is ETA approved and CE Marked. Design to provide up to 4 hours integrity and 2 hours insulation on a wide range of applications the FCPS will allow additional services to be added or removed and will accommodate thermal and mechanical movement of services.

Functionality

FCPS is a rock fibre core coated with ablative sealant FPC for use in both vertical and horizontal applications.
It maintains the sound reduction index of a structure.
The FCPS will allow additional services to be added or removed and will accommodate thermal and mechanical movement of services.
FPC can be used to adhere sections of FCPS board when jigsaw assembly is required and can also be used to enhances smoke and acoustic performance.
