Notched channel bolt for excellent strength and safety.

Channel bolt FBC-N

Notched channel bolts for use in combination with smooth hot-rolled anchor channels, which notch into the back of the channel lip when the installation torque is applied.

Product variants

Approvals / Test reports

18 Product variant (s)

Profile

Thread

Length

Match

Amount

GTIN (EAN-Code)

Legend = Permission Available— = Permission not Available

Viewed 18 of 18 variant (s)

Advantages

FBC-N bolts with notched underside perfectly fitting to hot-rolled Cast-in channel lips.
Thus giving excellent load capacity with high safety.
All directional load capacity.
Plus fundamental load capacity in longitudinal direction.
Ideal prepositioned fixing solution, capable of covering on-site tolerances.
Suitable for applications in cracked and non-cracked concrete.
Permanently adjustable fixing solution.

Properties

Hot-dip galvanised ≥ 50 µm acc. to EN ISO 10684:2004 + AC:2009
Steel grade 8.8 acc. to EN ISO 898-1:2013
Hexagonal nut acc. to EN ISO 4032:2012

ETA Certification Document

pdf, ETA-18/0862

European Technical Assessment for fischer Anchor Channel FES with fischer Channel Bolts FBC

Created on 31/03/2023

DOP - Declaration of Performance

pdf, DoP No. 0333

Declaration of Performance for fischer Anchor Channel FES with fischer Channel Bolts FBC (Anchor channels for use in concrete)

Created on 25/07/2023

Technical Data Sheet

pdf,

FBC-N-50/30-HDG Channel bolt

ETA-approval
Profile	FBC-N-50/30
Thread ( M )	M16
Length ( l )	50 mm
Match	FES-H-50/30 / FES-H-52/34
Amount	50 pcs.
GTIN (EAN-Code)	4048962522839

ETA-approval
Profile	FBC-N-50/30
Thread ( M )	M20
Length ( l )	125 mm
Match	FES-H-50/30 / FES-H-52/34
Amount	20 pcs.
GTIN (EAN-Code)	4048962522983

ETA-approval
Profile	FBC-N-50/30
Thread ( M )	M20
Length ( l )	60 mm
Match	FES-H-50/30 / FES-H-52/34
Amount	25 pcs.
GTIN (EAN-Code)	4048962522938

ETA-approval
Profile	FBC-N-50/30
Thread ( M )	M16
Length ( l )	100 mm
Match	FES-H-50/30 / FES-H-52/34
Amount	25 pcs.
GTIN (EAN-Code)	4048962522884

ETA-approval
Profile	FBC-N-50/30
Thread ( M )	M16
Length ( l )	125 mm
Match	FES-H-50/30 / FES-H-52/34
Amount	20 pcs.
GTIN (EAN-Code)	4048962522891
